he Commander 1300 is an all-ability level Foil Assembly built with a mix of carbon and aluminum parts. The front wing is prepreg carbon fiber with a polyurethane core measuring at 1328.6 cm2 and the rear wing lands at 227 cm2. The fuselage and mast are constructed with high quality 60/61T Aluminum, fuselage is 60.3 cm in length and the mast has a depth of 28.52”. The Commander 1300 utilizes M8 hardware throughout and will pair with any foil board on the market today.
CONSTRUCTION FEATURES / SPECS
• Carbon Fiber & 6061T Aluminum Construction
• Beginner Friendly Stable Wing Design with added Maneuverability
• Front Wing – Carbon Fiber / PU Foam Core
– Wingspan: 72.6 cm (28.57”)
– Wing Chord: 18.3 cm (7.2”)
– Wing Area: 1328.6 sq cm (205.9 sq inch)
– Aspect Ratio: 4:1
– Wing Angle: 0.6 Degrees
• Rear Wing – Carbon Fiber / PU Foam Core
– Wingspan: 34.1 cm (13.43”)
– Wing Chord: 9.1 cm (3.58”)
– Wing Area: 227 sq cm (35.2 sq inch)
– Aspect Ratio: 5.1:1
– Wing Angle: -2.5 Degrees
• Mast – Aluminum Extrusion 6061T
– Height: 72.5 cm (28.52”)
– Chord: 11.5 cm (4.53”)
• Fuselage – Machine Aluminum 6061T
– Length: 60.3 cm (23.75”)
• Fasteners – M8
